Technical Specifications Maximum hole center 1000mm ( 39 - 1/4”) Glass thickness 3mm - 40mm (1/8 – 1 - 5/8”) Glass Hole Size 4 - 100mm (5/32 – 4”) Power* 2.2KW (220V, 3phase, 60Hz) Weight 800Kg (1770lb) Base Dimension 1.66m*0.82m*1.6m (66 x 32 x 63”) GEM - GDM80 Glass Drill Machine - Opposing drill heads produce nice clean hole. - Hole centering is by means of mechanical or laser light method. - A Pneumatic clamp holds the glass with adjustable pressure. - The machine has two working modes: semiautomatic & automatic. - This machine uses oil damping technology for controlling the movement of the drill spindles. * Special Voltage requirements to be specified by Customer. Machines are sold as CE rated.
GEM Horizontal Glass Drilling Video
