Brief Description:  The machine is designed for the grinding and polishing of exterior edges of shaped glass.  By changing the grinding wheel, different edge profiles (flat edge with arris, pencil edge, bevel edge and OG edge) can be processed.  The height of the spindle is easily adjusted with motorized or handwheel control.  A pneumatic cylinder (included attachment) makes it possible to process round glass automatically.  The turntable drive motor and worm gear are installed in the base housing. Its speed is adjusted through a step - less regulator. GSBM20 Specifications: Bevel Angle 5 – 20 degrees Glass Thickness 3mm - 30mm (1/8 ” – 1 - 1/4”) Glass Diameter 100 - 2000mm (4” – 78”) Weight 500Kg (1100 lbs) Total Power* 2.8KW Dimensions 1.5mx1.5mx1.6m (59” x 59” x 63”) GSBM20 – Shaped Glass Edging Machine (Outer Edge Processing)
* Special Voltage requirements to be specified by Customer.  Machines are sold as CE rated.
Glass Shape Edging Machines
